Cubex QXR920 drill series are designed to switch flexibly between production drilling, pre split drilling or horizontal drilling. Optional attachments allow for RC sample drilling
Cubex QXR920 GEN IV
Build 2004
Current Frame hours is 16,896
Major rebuild in 2019 including
Sullair 900/500 or 1050/350
Caterpillar CAT C15 540hp @ 1800 Rpm in frame to the Caterpillar (3,918 hrs current)
Cubex – 6230 rotation head
0-80 Rpm with 5730 Nm torque
6 rod carousel
Hammer lube system
7.3m stroke
47Kn pull down / pull back
